How to choose the right elevator panel

The electric power of the elevator motor, which is the driving force of the system. The nominal and instantaneous currents that are included on the plate are one of the parameters for selecting elements of the elevator control panel. For example: the electric motor with a power of 5.5kw and a rated current of 14 amps should be started with a panel that has a speed control drive of 7.5 kw with a tolerance of at least 17 amps. It is also calculated based on the drive range of the contactors. The power of the electric motor is calculated based on displacement capacity and can be found on the motor nameplate.

The height or the length of the elevator movement path is a parameter that should be taken into account when selecting the board. Increasing the height causes a change in the selected range of the speed control drive.

Traffic refers to the type of use of the building and the number of its units. The calculation of the elevator control panel is based on traffic: low traffic, medium and high traffic. commercial buildings, hospitals and sometimes industrial buildings have the most traffic during office hours, which increases the utilization factor and confidence in the calculation. In group elevators, group control of the elevator has a very important role in service and movement, which is made possible by advanced group panels.

Another parameter involved in the calculation of the drive and control and control panel is the speed of the elevator movement, which apart from the calculation of the drive power must be carefully considered in the relevant software and controls, the calculations of elevators above one and six meters per second are very different. And it is more sensitive than common elevators that have a speed of one meter and one and six tenths of a meter per second.

One of the most important factors in choosing a good and easy board is the speed of the support service, which encourages the consumer. Considering that the safety systems of the elevator are the main factors of its failure and the number of these safety systems is very large. Its executive requirements are from the orders of Iran's National Standards Department. The service and support of the panel manufacturer plays a very effective role in improving the performance of the elevator.

The beauty of a panel is a sign of production order and respect for consumer rights, and it promotes the industry and beautifies the executive work, therefore, it is necessary to choose a panel that, in addition to correct performance and good feedback from past customers, has A stylish and suitable appearance with a beautiful body and a suitable and quality color and compliance with ergonomic issues for installers and repairers should be considered in the design of a panel.

Another important issue in choosing a suitable panel is its up-to-dateness and the use of up-to-date elements and new technology. Today, due to the unprecedented growth of electrical and electronic technology and the new generation of speed control drives for elevators, they have special features. which makes the elevator comfortable and optimally used. For example: one of the most important parameters in moving and increasing the speed of moving and reducing the passenger's waiting time is the reduction of the walking speed based on the glass movement or the direct eyebrow and the opening before the stop or the advance opening in all signs and drives. Clock control becomes normal. In such a way that the elevator does not start slowing down in order to stop understanding the text at the best time and distance and at the right speed, and at the same time opens the doors of the functions, and this feature also improves the traffic situation.

Features and special features of the floating board Choose a board that has practical features and special features. This means that the consumer can meet his special needs with a common elevator sign, for example, a common sign with a reasonable price. It should have at least the following features. Park mode on a specific floor of any floor chosen by the user. There are two resting modes, in which the truck's lights are turned off and it waits for the steering wheel Canceling a chassis that has been hit by mistake, which is provided by pressing the desired thumb again Stopping in the first stop during a power failure which is performed by the UPS and the emergency power system Announcement of elevator failure by the display inside the panel The location of sending the failure and its type by the GSM board of the control panel of the local operators of the repairer's mobile phone Class announcement and speaker and playing music in the cabin Easy access to panel settings by elevator repairman Proper lighting inside the panel separately Inspection box and the possibility of controlling the movement of the cabin for inspection and repair
