Introducing Pre -Model Wall Mold
These molds are made of metal and 4 sides can be molded in different ways. After concreting, the molds are opened and cleaned for the next time. Precast concrete wall molds are a part of large panels. Large panels are forms in which all sides are concreted at the same time, so the prefabricated walls are integrated.
prefrontal wall categorization
Prefabricated walls can be divided into different categories based on the execution method factor and the facade factor. If we want to categorize the walls based on their appearance, they will be as follows:
- Single sided wall
- Double sided wall
But if prefabricated walls according to the implementation method factor, they are:
Lying concrete wall template: This method is used when the prefabricated wall that we intend to implement is one-sided. br> Standing wall template: When the prefabricated wall is double-faced, we implement this wall with standing template.
Battery wall template: This template is like this that a number of prefabricated wall molds are placed vertically together and concreted simultaneously. The name of this format is the battery format because of the appearance of this system.
What structures do the pre -made wall molding?
Prefabricated wall formwork is used in the framing of huge construction projects because the cost of its implementation is lower than other walls such as brick walls and walls that are built with mortar, and also its implementation happens faster. The prefabricated concrete wall is used in walling of large structures such as factories and workshops, villas and gardens, stadiums, residential complexes and sheds.
What dimensions are made of pre -made wall molds?
It was stated earlier that the sizes of prefabricated wall molds are diverse and they are designed and manufactured according to the customer's order and according to the needs of the project in different models and dimensions. The type of project is expressed in certain sizes. The length of prefabricated wall forms is up to 4 meters and the height of prefabricated walls is between 1.2 and 3 meters. Regarding the thickness of the prefabricated wall, the height of the wall is relevant. The thickness of the wall is determined according to its height, which is between 11 and 15 cm as a standard.
