cubic fiberglass cooling tower of 20 tons
250 tons of refrigeration fiberglass cooling tower
Engine power: 5.5 horsepower Normal water flow rate: 880 gallons per minute Fiberglass body, pan and throat Dimensions (height, length, width): 360 * 250 * 250 cm PP splash net packing (or PVC packing) Model DTC-CO 250 Capacity (TR) of 250 tons of refrigeration Normal water flow (GPM) 880 Engine power (HP) 5.5 (KW) 4 Dimensions (cm), length 250 Width 250 Height 360 Fan diameter (cm) 180 Fan flow rate (CFM) 66500 Weight (kg) 1775 The size of the fittings (inch), 3 inch aluminum flange, 3 pcs Output 6 Overflow size (inch) 2 Discharge size (inch) 2 Floating size (inch) 1 Special features equipped with a 2h anti-deposit polypropylene nozzle, anti-clog, screwdriver, easy to open, with acid washing capability. Has the ability to acid wash (anti-scald) Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts Equipped with structure and plated metal parts Elminator (drip catcher) made of P.V.C honeycomb design (P.P material) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of anti-UV gel coat.
200 ton fiberglass cooling tower
Engine power: 2 horsepower Normal water flow rate: 705 gallons per minute Fiberglass body, pan and throat Dimensions (height, length, width): 350 * 220 * 220 cm PP splash net packing (or PVC packing) Model DTC-CO 200 Capacity (TR) of 200 tons of refrigeration Counterflow operation - open circuit Normal water discharge (GPM) 705 Engine power (HP) 2 (KW) 1.5 Dimensions (cm), length 220 Width 220 Height 350 Fan diameter (cm) Multiwing 120 made of fiberglass 7 blades Fan flow rate (CFM) 47000 Weight (kg) 1301 The size of the fittings (inch), 3 inlets, 3 inches Output 1 number of 6 inch output Overflow size (inch) 2 Discharge size (inch) 2 Floating size (inch) 1 Special features equipped with anti-fouling square spray nozzles and high pressure injection pipes Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts Equipped with structure and plated metal parts Elminator (drip catcher) made of P.V.C honeycomb design (P.P material) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of anti-UV gel coat.
Cuban Fiberglass Cooling Tower 300
Engine power: 5.5 horsepower Water flow rate: 1050 gallons per minute Fiberglass body, pan and throat Dimensions (height, length, width): 400 x 300 x 300 cm Splash net packing made of P.P (or P.V.C packings). DTC-CO 300 model Capacity (TR) of 300 tons of refrigeration Function Counterflow - open circuit Normal water flow (GPM) 1050 Engine power (HP) 5.5 (KW) 4 Dimensions (cm), length 300 Width 300 Height 400 Fan diameter (cm) 220 Fan flow rate (CFM) 77000 Weight (kg) 1866 The size of the fittings (inch), 3 inlets, 3 inches Output 1 number of 6 inch output Overflow size (inch) 2 Discharge size (inch) 2 Floating size (inch) 1
Special features equipped with anti-fouling square spray nozzles and high pressure injection pipes
Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts. Equipped with structure and plated metal parts Elminator (drip catcher) made of P.V.C honeycomb design (P.P material) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of anti-UV gel coat.
cubic fiberglass cooling tower 500
Engine power: 15 horsepower Water flow rate: 1770 gallons per minute Fiberglass body, pan and throat Dimensions (height, length, width): 400 * 350 * 350 cm PVC splash net packing (pvc packings) Model DTC-CO 500 Capacity (TR) of 500 tons of refrigeration Counterflow operation - open circuit Normal water discharge (GPM) 1770 Engine power (HP) 15 (KW) 11 Dimensions (cm), length 350 Width 350 Height 400 Fan diameter (cm) 220 Fan flow rate (CFM) 119600 Weight (kg) 3235 The size of the fittings (inch), 4 inlets, 3 inches Output 1 number of 8 inch output Overflow size (inch) 2 Discharge size (inch) 2 Float size (inch) 1
Special features equipped with anti-sediment square spray nozzles and high pressure injection pipes
Equipped with European Siemens or Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts
Equipped with plated metal structure and parts Elminator (drip catcher) made of P.V.C honeycomb design (or V-bar design made of P.P) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of anti-UV gel coat.
Engine power: 2 horsepower Normal water flow rate: 528 gallons per minute Body, pan and throat Technical specifications of 150 tons of refrigeration Model DTC-CO 150 Capacity (TR) of 150 tons of refrigeration Counterflow operation - open circuit Normal water discharge (GPM) 528 Engine power (HP) 2 (KW) 1.5 Dimensions (cm), length 200 Width 200 Height 340 Fan diameter (cm) 140 Fan flow rate (CFM) 29000 Weight (kg) 866 The size of the fittings (inch), 3 inlets, 3 inches One 4 inch outlet Overflow size (inch) 2 Discharge size (inch) 2 Floating size (inch) 3/4 Special features equipped with anti-fouling square spray nozzles and high pressure injection pipes Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts Equipped with structure and plated metal parts Elminator (drip catcher) made of P.V.C honeycomb design (or V-bar design made of P.P) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of gelcoat coating.
Engine power: 2 horsepower Normal water flow rate: 352 gallons per minute Fiberglass body, pan and throat Dimensions (height, length, width): 340 * 200 * 200 cm PP splash net packing (or pharmaceutical grade PVC packing) Technical specifications of 100 tons of refrigeration Model DTC-CO 100 Capacity (TR) of 100 tons of refrigeration Counterflow operation - open circuit Normal water discharge (GPM) 352 Engine power (HP) 2 (KW) 1.5 Dimensions (cm), length 200 Width 200 Height 340 Fan diameter (cm) 120 Fan flow rate (CFM) 24000 Weight (kg) 638 The size of the inlet fittings (inch) is 2 pieces of 3 inches 1 outlet of 4 inches Overflow size (inch) 2 Discharge size (inch) 2 Floating size (inch) 3/4 Special features equipped with anti-fouling square spray nozzles and high pressure injection pipes Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and depreciation of parts Equipped with deep galvanized structure and metal parts Elminator (drip catcher) made of P.V.C honeycomb design (or V-bar design made of P.P) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of gelcoat coating
80 tons of refrigeration fiberglass cooling tower
40 tons of refrigeration fiberglass cooling tower
Fiberglass body, pan and throat
Dimensions (height, length, width): 300 * 150 * 150 cm
P.P splash net packing (or P.V.C packing)
60 ton refrigeration cubic fiberglass cooling tower model
Capacity (TR) 60 ton refrigeration
Counterflow operation - open circuit
212 normal water flow rate (GPM).
Engine power (HP) 1
(kw) 0.75
Dimensions (cm) Length 150
Width 150
Height 300
Diameter of the fan (cm) 85
Fan flow rate (CFM) 14500
Weight (kg) 359
Connection size (inch) Input 2 pcs 2 inches
Output 1 pcs 3 inches
Overflow size (inch) 1/2 1
Drainage size (inch) 1/2 1 Floating size (inch) 3/4 Special features equipped with anti-fouling square spray nozzles and high pressure injection pipes
Equipped with Motogen Tabriz electric motors with the ability to install an inverter to reduce electricity consumption and depreciation of parts
Equipped with structure and plated metal parts
eliminator (droplet catcher) made of P.V.C honeycomb design (P.P material) All body components, louvres, pan and throat molded with the latest method of the day, to increase durability The body, pan and throat are made of fiberglass, made of the best type of resin and the thickest, with two layers of anti-UV gel coat.
40 tons of refrigeration fiberglass cooling tower
Motor power: 1 horsepower
Normal water flow rate: 141 gallons per minute
Body, pan and throat made of fiberglass
Dimensions (height, length, width): 280 x 125 x 125 cm< br>P.P splash net packing (or P.V.C packing)
DTC-CO 40 model
Capacity (TR) 40 tons of refrigeration
Function
Counterflow - open circuit
Normal flow of water (GPM) 141 Motor power (HP) 1 Dimensions (cm) Length 125 Width 125 Height 280 Fan diameter (cm) 85 Flow rate Fan (CFM) 9400
Electric motor(kw) 0.75
Weight (kg) 230
Connection size (inch) Inlet 1 piece 3 inch
Outlet 1 piece 3 inch
Overflow size (inch) 1
Discharge size (inch) 1
Floating size (inch) 3/4
Special features equipped with anti-sediment square spray nozzles and high pressure injection pipes
Equipped with Motogen Tabriz electric motors with the ability to install an inverter In order to reduce electricity consumption and depreciation of parts, equipped with plated metal structure and parts, eluminator (drip trap) made of P.V.C, honeycomb design (P.P material), all body components, louvres, pan and molding throat. Made with the latest method of the day, to increase durability
body, pan and throat made of fiberglass, made of the best type of resin and the thickest with two layers of anti-UV gel coat coating
40 tons of refrigeration fiberglass cooling tower
Engine power: 1 horsepower
Normal water flow: 141 gallons per minute
Fiberglass body, pan and throat
Dimensions (height, length, width): 280 x 125 x 125 cm< br>P.P splash net packing (or P.V.C packing)
DTC-CO 40 model
Capacity (TR) 40 tons of refrigeration
Function
Counterflow - open circuit
Normal flow of water (GPM) 141 Motor power (HP) 1 Dimensions (cm) Length 125 Width 125 Height 280 Fan diameter (cm) 85 Flow rate Fan (CFM) 9400
Electric motor(kw) 0.75
Weight (kg) 230
Connection size (inch) Inlet 1 piece 3 inch
Outlet 1 piece 3 inch
Overflow size (inch) 1
Discharge size (inch) 1
Floating size (inch) 3/4
Special features equipped with anti-sediment square spray nozzles and high pressure injection pipes
Equipped with Motogen Tabriz electric motors with the ability to install an inverter In order to reduce electricity consumption and depreciation of parts, equipped with plated metal structure and parts, eluminator (drip trap) made of P.V.C, honeycomb design (P.P material), all body components, louvres, pan and molding throat. Made with the newest method of the day, to increase the durability
body, pan and throat made of fiberglass, made of the best type of resin and the thickest with two layers of anti-UV gel coat
250 tons of refrigeration fiberglass cooling tower
Motor power: 5.5 horsepower
Normal water flow rate: 880 gallons per minute
Body, pan and throat made of fiberglass
Dimensions (height, length, width): 360 * 250 * 250 cm< br>P.P splash net packing (or P.V.C packings)
DTC-CO 250 model
Refrigeration capacity (TR) 250 tons
Normal water flow rate (GPM) 880
Motor power (HP) 5.5
(KW) 4
Dimensions (cm) length 250
width 250
height 360
fan diameter (cm) 180
fan flow rate (CFM) 66500
Weight (kg) 1775
Connection size (inch) inlet 3 inch aluminum flange 3 pcs
Outlet 6
Overflow size (inch) 2
Drain size (inch) 2
Floating size ( 1 inch)
Special features equipped with a 2h anti-deposit polypropylene anti-clog nozzle, easy to open, with acid wash capability Electricity and parts depreciation
Equipped with structure and plated metal parts
Eliminator (drip trap) made of P.V.C honeycomb design (P.P material)
All body components, louvres, pan and throat molded with the latest Today's method, to increase durability
body, pan and throat made of fiberglass, made of the best type of resin and the thickest with two layers of anti-UV gel coat coating
cubic fiber cooling tower;
Motor power: 2 horsepower
Normal water flow rate: 528 gallons per minute
Body, pan and throat
Technical specifications of 150 tons of refrigeration
DTC-CO 150 model< br>Capacity (TR) 150 tons of refrigeration
Counterflow operation - open circuit
Normal water flow rate (GPM) 528
Motor power (HP) 2
(KW) 1.5
Dimensions (cm) Length 200
Width 200
Height 340
Fan diameter (cm) 140
Fan flow rate (CFM) 29000
Weight (kg) 866
Connection size (inch) Input 3 inputs 3 inches
one outlet 4 inches
overflow size (inch) 2
discharge size (inch) 2
float size (inch) 3/4
special features equipped with square spray nozzles Anti-fouling and high-pressure injection pipes
Equipped with Motogen Tabriz electric motor with the ability to install an inverter to reduce electricity consumption and parts wear
Equipped with structure and plated metal parts
Elminator (drip catch) made of P.V.C nest design Beehive (or P.P V-bar design)
All body components, louvres, pan and throat molded with the latest method of the day, to increase durability
Body, pan and throat made of fiberglass, made of the best type Resin and the highest thickness with two layers of gel coat coating
