💠 Package performance in summer mode 💠
In this case, when the package starts working when hot water is needed, this operation is done automatically. When the hot water tap is opened, the pressure sensor turns on the torch, and after closing the hot water tap, the package is turned off. This command is issued through the electronic control board. The shell-tube secondary heat exchanger immediately produces hot water. produces.
💠 Package performance in winter state 💠
The duty of the spa package is different in the winter season. Because in addition to heating the consumed water, it must also heat the radiator and heating circuits. In this system, priority is given to hot water consumption. When the hot water tap is opened. The electric sensor cuts off the radiator circuit as long as the hot water supply is open. But this is temporary and it is connected to the radiator when the hot water valve is closed. In this way, hot water is always available instantly.
How does the package work?
"Production of hot water consumed by the package"
In the upper part of the burner of each package, there are pipes with cold water coming in from one side and hot water coming out from the other side. will be These pipes are designed as a complex so that they reach the temperature specified on the package in an optimal way, and also their design is such that hot water is provided uniformly by the package. In the path of the pipe, there is a flow sensor or flow switch, which is installed in the package in order to detect the opening of the hot water valve. When the hot water valve is opened, the sensor detects the water flow and immediately orders the burner and pump to turn on, and the hot water from the package reaches the valve outlet in a few moments. In some types of packages, there is a small tank to store a small amount of hot water, which fulfills several purposes:
- Firstly, with the presence of a hot water source, the burner's performance is reduced and the final life of the package is increased.
- Secondly, the presence of this tank in the package reduces water wastage. In such a way that with the presence of the hot water return pipe, the wait for hot water to come out of the tap is reduced and as soon as the tap is opened, the water comes out with the desired temperature. The heat in the package prevents these pipes from rotting and sedimentation.
"Heating with the help of hot water in the heater and underfloor heating by the package"
The air conditioning heating system needs several tools and systems to work efficiently. These tools and mechanisms are located in the central heating facilities of buildings in different parts of the building. This is while all these devices are properly placed in the package. Devices such as burners, expansion sources, thermostats, pumps, sensors, hot water boilers, etc. They are somehow placed inside the package compartment so that they can perform the assigned tasks efficiently and optimally in this small space. When the heaters are opened or the floor heating pipes are opened, the hot water produced in the burner goes directly from the package to the radiators, or by a double-layer heat exchanger, the heat from the hot water produced by the burner goes to the hot water consumed by the radiators. is transferred This converter can also supply the heat required for hot water used in the bathroom and other water consumers. Controlling the heating of consumed water and heating water is done by the three-way electric valve included in the package. This valve is managed and adjusted by the control panel of the package. This valve can be adjusted in three modes of heating the water used alone or heating the heating water or both. According to the settings that the user makes in the package panel and also with the help of the sensors in the package, the state of this valve is automatically adjusted and sends hot water to the places of consumption in a managed and optimal way.
