The elevator cabin is one of the important and main parts of the elevator, where people or loads are placed inside and move between the floors of the building. One of the most important things in buying an elevator is choosing the dimensions of the elevator chamber, which should be chosen according to the capacity of the people who use it and according to the size of the elevator shaft in the building. The elevator cabin consists of four main parts, which are: - The yoke or the main frame - The platform on which passengers and cargo are placed. - The walls that are used as protection. They include side walls, floor, ceiling, interior coverings and cabin decorations.
- elevator cabin door
Elevator cabin body
The body of the elevator cabin should be made in such a way that it does not collide with the walls of the elevator well during movement. Usually, the body is made of something like steel, which is very resistant, strong and non-flammable. They are considered to be 1.5 mm thick steel sheets. The body is made in the form of slats with dimensions of 30 to 40 cm and the length of the height of the elevator cabin and they are screwed. The edge of the slats is turned back approximately 3.5 to 4 cm to strengthen the body when bolting them together.
The roof and floor of the elevator cab
The material of the cabin floor should be so resistant that it has enough hardness against the pressure exerted by the cargo and passengers. The main roof of the cabin is made of 2 mm galvanized sheet and its floor is usually made of granite stone. The thickness of the roof and floor of the cabin should be at least 2 cm.
Elevator cabin yuk
The frame holding the cabin is called a yoke. They are usually made of resistant metal to which cabin parts are attached during installation.
Elevator cabin door
Another important component of the elevator is the cabin door, which ensures the safety of passengers and prevents them from accessing dangerous environments. When buying and installing it, we must be careful enough so that the elevator is completely flawless. Its material should be very resistant to impact and pressure. Elevator cabins are made with various doors, which include the following:
- Elevator cabin with fully automatic telescopic door
- Elevator cabin with semi-automatic telescopic door
- Elevator cabin with fully automatic central door
br>- Elevator cabin without door
