Introducing Ceiling Jack
One of the widely used products in all kinds of construction projects is the roof jack. As the name suggests, these equipment are jacks that are used to support the load on the roof. It is necessary to know that this product is used for almost all roofs in order to increase endurance and stability.
Specifications of ceiling jack
The bottom and top of this product are made of pipe and have the following specifications:
Bottom part:
Pipe diameter: 6 cm
Thickness: 2 mm
Upper part:
Pipe diameter: 5 cm
Thickness: 2.5 mm
In general, this product can bear a maximum load of 1.5 tons. Its standard size is available in the market with a height of 3.20 meters and a weight of 14 kg. It should be noted that, excluding the jack head, its weight is between 12.5 and 21 kg.
What are the constituents of the building jack?
What is the most common type of ceiling jack?
Ceiling jacks are produced and marketed in different types, the most common of which are as follows:
No cross
fixed cross
Iraqi U shape
Mobile T shape
a candle
Telescopic
Jack without cross: Jack without cross is used to build concrete roofs and it is the simplest type.
Fixed cross ceiling jack: This type of jack has a fixed cross and no flexibility, which causes limited use in some places, however, it is one of the most popular types of ceiling jacks.
Iraqi U-shaped ceiling jack: This type of jack is designed to be adjustable for use at different heights. Its opening is relatively small, and it is suitable for carrying out ceiling beams and maintaining bridges.
Mobile T-shaped ceiling jack: in this type of jack, it is possible to rotate, so it can bear less load than other jacks.
Benefits of Ceiling Jack
High execution and installation speed
light weight
Reusable
Economical
Applications of Ceiling Jack
Ceiling jacks are used in all kinds of construction projects. This product is one of the most essential materials for any building. The most important uses of this product are as follows:
Roof framing
Keeping the load of the roof until the end of the construction of that floor
