Introduction

key prerequisites before installing a road scales in Hormozgan province

Select the exact location of the installation

correct location is the most important factor in your efficiency and longevity. The following points should be paid to the following:

Land strength: The soil of the area must have sufficient density and resistance to withstand the weight of concrete foundation and dynamic loads caused by the traffic of trucks. Geotechnical testing is highly recommended for large projects.

Groundwater levels: Given the nearby underground water level, the groundwater level is high. The installation site should be selected to prevent water from penetrating the foundation and electronic components.

Proper drainage: The location must have a natural slope or engineered drainage system for rapid drainage of rainwater to prevent the accumulation of water around and under the scales. Water accumulation is the main cause of the corrosion of the structures and damage to the loads.

Maneuver sufficient space: There must be enough space at the beginning and end of the scales for direct entry and exit and without the bolt of trucks. At least 5 to 10 10 meters of direct route on each side is recommended.

Avoid tremor and electromagnetic sources: Basque should not be installed in the vicinity of heavy machinery or high -pressure power posts.

selection of scrolls tailored to Hormozgan conditions

Two of the main choices ahead of you, each with its own advantages:

Concrete Prefabricated Road Basque:

This type of scales is an ideal option for Hormozgan province due to its high resistance to corrosion and rust. Concrete -type road scalp installation will maximize your durability and longevity of investment.

Metal Road Scale:

These scales have a higher installation speed but are more vulnerable to moisture and salt. If you choose this model, the use of very strong protective coatings such as multilayer epoxy paint and continuous inspections to prevent rust is required.

Step by Step Steps to Installation of Road Basque

The process of installing road scales is a precise and multi -step operation that must be carried out by a specialist team with full compliance with engineering maps.

Step One: Design and Preparing Maps

After the initial consultation and selection of the type and capacity of the scales (eg 60 tons scales), the Sohrabi Nejad Basco -Engineering team designs precise foundations based on the technical specifications of the scales and the project location of the project. These maps include the exact dimensions of the excavation, the details of the reinforcement, the location of the drainage pipes and the cables.

Step Two: Decorating and preparing the bed

This is the most sensitive part in the process of installing road scales. excavation: The excavation operation is carried out exactly in accordance with the dimensions and depth specified on the map. Level and compact: The floor of the pit should be fully aligned and to the desired density using a roller or compact to prevent future foundations. Running Concrete Unless: A low -grade concrete layer (concrete) is about 10 cm thick on the floor of the pit to provide a smooth and clean surface for reinforcement and prevent direct contact with the soil.

Step Three: Reinforcement and Formation Formatting

Basque foundation is its spine. High -precision Bascoleneneneh -e -Sahrabinejad executive team runs the bars (reinforcement) exactly based on the engineering map on the floor and walls. The quality and size of the bars and the distance between them have a direct impact on the final strength of the foundation. After the reinforcement, metal or wooden molds are installed to shape the concrete. At this point, the cable pipes and drainage pipes are also located in their exact location.

Step Four: Concrete Foundation

Concrete should be performed using the appropriate grade concrete (usually 25c or 30c30 resistance) and integrated. Using vibrator is required to remove air bubbles and compress the concrete completely. After concrete, the vital stage of the concrete practices begins. In the hot climate of Hormozgan, maintaining the moisture of the concrete through continuous spraying or using special coatings for at least 7 to 14 days is essential to achieve maximum concrete resistance.

Step Five: Installation of Mechanical Parts

Once the foundation has reached the necessary resistance, the installation of the main parts begins:

Installation of Base Plates: The metal plates on which the loadals are mounted are accurately installed and aligned on the foundation.

Loads Installation: Luddlers (weighing sensors) are mounted on the base pages. The scales platform, both metal or concrete, is placed on the loads using heavy crane.

Stoppers Installation (Stoppers): To prevent the platform's lateral and longitudinal movements by brake or truck acceleration, the limits are installed.

Step 6: Installation of Electronic Equipment

This step of launching road scales requires expertise in the field of electronics and precision tools. Cable: The cables of each loadll are transferred to the Junction Box through pre -embedded pipes. Jiors Boxing Connections: All cables inside the box of boxes that must have high protection (IP67 or IP68) for moisture resistance are correctly attached. Installation: The output cable from the box box is connected to the weight display, which is usually installed in the Basque Chamber.

Final Stage: Launching and Calibration of the Road

After the installation of the road scales, the process of setting up and adjustment begins, which is called calibration. This step is critical to ensure accuracy and accuracy of the scales and must be done by qualified experts.

Initial Settings: Sohrabi Nejad Basque expert enters the initial display settings including the final capacity, display accuracy, and parameters related to the loadal.
Calibration with standard weights: This is the most important part of the job. Using precision and standard weights approved by the National Iranian Standard Organization, the scales are tested and tested at different parts of their capacity (eg 20 % 20 %, 50 % 50 % and 80 % 80 % total capacity). The goal is to make the error displayed as low as possible and within the standard permitted range.
Standard approval: After successful calibration, the scales are ready to be inspected by the National Standard Organization experts and receiving the performance accuracy certificate. Sohrabi race will accompany you at all stages of this process.

Why is the best choice for installing a road scales in Hormozgan, Sohrabi Nejad?

Drawing a sensitive road installation project in Hormozgan province to a professional team is a secure investment. Our collection is distinct for the following reasons: Specialty in Native Conditions: We are well acquainted with the climatic and geographical challenges of Hormozgan province and provide engineered solutions to deal with corrosion and moisture. Provide zero -to -100 services: from initial consulting and design to full implementation of foundation, installation, calibration and obtaining the necessary permits, we are along the way. Experienced Executive Team: Our technicians and engineers have years of practical experience in installing road scales throughout the country. Quality Assurance and accuracy: We guarantee the perfect performance of your scales using the best materials, original electronic components and accurate calibration. Support and after -sales service: Our commitment will not end with the completion of installation. We will always be backing up your capital by providing maintenance and repair services.

conclusion

Installation of road scales in Hormozgan province beyond putting together a few pieces of iron and concrete; This is a precise engineering process that the future of your business is tied to. An uncomitant installation can turn the most accurate scales into a costly and costly tool.

Sohrabi Nejad's scrolls make your dream of having a precision, durable and standing standards by providing comprehensive and specialized solutions. If you are looking for a reliable partner for your road scroll installation project in Bandar Abbas, Qeshm, Kish, Bandar Lengeh or anywhere else in Hormozgan province, contact our experts today and enjoy free expert advice.
