Today, in the world of industry and production, moving heavy loads is one of the main challenges of factories and industrial sheds. Construction of cranes is known as one of the vital elements in production lines, warehouses and construction projects. If you are the owner of an industrial business or you intend to equip your workshop, knowing the steps from zero to one hundred of manufacturing industrial and workshop cranes can help you choose the best option. In this specialized article, we will examine all aspects of the design, production and installation of these giant structures and we will introduce the role of Parsian Atlas Crane Company as one of the pioneers of this industry.

The importance of making cranes in modern industries

Cranes are not just tools for lifting loads; They are considered the main artery of material transfer in a factory. A short stop in the operation of the crane can paralyze the production line for hours. Therefore, quality is the first word in the construction of cranes. The production process of this equipment requires complex engineering knowledge, high-quality raw materials and compliance with international standards. Parsian Atlas Crane Company, with years of brilliant experience, has been able to launch products on the market that are at a high level in terms of safety and efficiency by combining modern knowledge and practical experience.

When we talk about crane manufacturing, we mean a precise engineering process that starts from the moment of customer needs assessment and continues until after sales service. Choosing the right contractor for the construction of overhead and gantry cranes is a long-term investment for your business.

Types of industrial cranes and their applications

Before entering the technical discussion and construction steps, we need to know which type of crane is suitable for your needs. Atlas Parsian Crane Company designs and produces a wide range of cranes, the most important of which are:

1. Construction of overhead crane

This type is the most common handling system in covered sheds. Construction of overhead cranes is done in two ways: single bridge and double bridge.

• Single-bridge overhead crane: It is suitable for smaller spans and lower capacities (usually up to 10 tons) and has a lower construction cost.
• Double-bridge overhead crane: It is used for heavy capacities and wide spans and is more stable. The engineers of Atlas Parsian Crane Company suggest the best option based on the dimensions of your shed with accurate calculations.

2. Construction of Gantry Crane

If you don't have a shed or a supporting roof, or if you intend to move cargo outdoors, building a gantry crane is the best option. These cranes have bases that move on rails installed on the ground. The construction of gantry cranes requires high accuracy in the alignment of the rails and the strength of the bases.

3. Construction of jib crane

For special workstations that need to move the load within a limited radius, a jib crane is used. This type of crane can be connected to the shed column or an independent column.

4. Construction of semi-gantry and hanging cranes

These models are designed for the special conditions of the shed architecture. Atlas Parsian Crane Company will carry out a detailed feasibility study for the implementation of these models by reviewing the plan of your workshop.

Step-by-step steps of making a crane in Atlas Parsian Crane Company

The zero-to-one hundred manufacturing process of industrial and workshop cranes in a reputable group such as Parsian Atlas Crane Company includes the following steps. Paying attention to the details in each of these steps will guarantee the longevity and safety of the device.

First step: detailed consultation and needs assessment

No project starts without a proper understanding of the customer's needs. Technical experts of Atlas Parsian Crane Company visit the project site first. The shed dimensions (length, width, height), load type, duty cycle and environmental conditions (humidity, dust, temperature) are checked. This information is vital for the optimal design and determination of the working class of the crane.

Second stage: design and engineering calculations

The beating heart of the crane manufacturing process is the design unit. Engineers prepare construction plans using advanced computing software. In this step, static and dynamic loads, bending of bridges, wind force (for external cranes) and incoming stresses are calculated. Atlas Parsian Crane Company is committed to carry out designs based on international standards such as FEM, DIN and ISO to ensure the safety of the structure.

The third step: choosing materials and buying raw materials

Output quality is directly dependent on input quality. Steel sheets with ST37 and ST52 alloys are usually used in the construction of industrial cranes. The type of sheet and its thickness are selected based on the calculations of the previous step. Atlas Parsian Crane Company procures all the raw materials from reliable manufacturers and controls the quality certificates of the materials to ensure that there are no defects in the steel structure.

Fourth stage: cutting and construction of metal structure (bridge and bridge)

After supplying the sheet, the cutting operation is done with precise CNC machines. In the construction of two-bridge overhead cranes, the wings and wings of the bridges are connected by specialized welding. The welding process at Atlas Parsian Crane Company is carried out under the strict supervision of welding engineers and using sub-powder and CO2 welding machines.

One of the important points in the construction of the crane is the negative rise (Camber), which should be included in the construction of the bridge so that after loading, the bridge becomes horizontal and does not sag. These are the technical subtleties that distinguish Atlas Parsian Crane Company from its competitors.

The fifth step: making longitudinal guides (End Carriages)

Guides or clegis are responsible for moving the crane along the shed. The wheels used in the guides should be made of forged steel or alloy cast iron with appropriate heat treatment so that they do not wear out quickly due to wear on the rails. Construction of cranes regardless of the quality of the wheels and longitudinal movement motors will lead to successive breakdowns and high repair costs.

Sixth step: cleaning and painting

Seventh step: Selection and installation of winch (Balancer) and mechanical equipment

Winch or hoist is the main mechanical part for lifting the load. In crane construction projects, towing or chain winches can be used. Parsian Atlas Crane Company guarantees the power and smoothness of load movement by supplying high-quality winches from prominent European and Asian brands (such as Demag, Kune Crane, Kito, Samsung, etc.) or high-quality internal assembly winches.

Eighth step: switchboard and control systems

The thinking brain of the crane is the electrical system and its control. The use of inverters in the electrical panel makes the movement of the crane smooth and without impact, which increases the life of the structure and prevents load fluctuations. Parsian Atlas Crane Company uses reliable brand parts such as Schneider or Siemens in the manufacture of electrical panels and installs safety systems such as limit switches (to limit movement) and collision sensors. Also, the longitudinal power supply system (power bus) is installed with high precision.

Step 9: Transport, installation and commissioning

After finishing the construction in the factory, the parts are transported to the project site. The installation team of Atlas Parsian Crane Company, with the necessary equipment, places the bridges on the carrier beam rails and establishes the connections. After the mechanical installation, cabling and start-up of the electrical system is done.

Tenth step: load test and final delivery

The most important step before delivery is to perform static and dynamic tests. The crane is tested with a load greater than the nominal capacity (usually 1.25 times) to ensure the strength of the structure and the performance of the brakes. After passing the tests, a health certificate and a capacity license plate are issued and the necessary training is given to the employer's operators.

Safety standards in the construction of workshop cranes

Safety compliance in crane construction is not a joke. The smallest negligence can lead to irreparable personal and financial accidents. The main standards that Atlas Parsian Crane Company adheres to are:

In addition, the installation of safety equipment such as "overload limiter" which cuts off the power of the device in case of overload, is mandatory in all crane construction projects of this company.

Factors affecting the price of crane construction

The cost of manufacturing industrial cranes depends on various parameters. Some employers are simply looking for a lower price, but it should be noted that lowering the price should not come at the cost of reducing safety. Factors affecting the price in Parsian Atlas crane company are clarified:

1. Carrying capacity (tonnage): The higher the tonnage, the greater the weight of the structure and the power of the equipment, and the price increases.
2. Span: The width of the shed directly affects the weight of the bridges and the type of design (single bridge or two bridges).
3. Lifting height: Determines the length of the towing wire or chain and the power of the lifting motor.
4. Brand Equipment: The use of European engines and gearboxes is more expensive than Chinese or Iranian models.
5. Additional possibilities: Installation of wireless remote control, magnets, hanging scales and inverters adds to the final price of crane construction.

Atlas Parsian Crane Company tries to establish the best balance between quality and your budget by providing honest advice so that extra costs are eliminated and efficiency is maximized.

maintenance and repairs; Supplement to basic construction

Even the best crane in the world will wear out without proper maintenance. One of the advantages of working with Atlas Parsian Crane Company is to benefit from powerful after-sales services. Maintenance (PM) services include periodic visits to the cables, oiling the transmissions, checking the brake pads, and tightening the connections. Building a crane is not the end of the road, but the beginning of our commitment. Supplying original spare parts as soon as possible eliminates the concern of stopping the production line for industry managers.

Why choose Parsian Atlas Crane Company?

In today's competitive market, claiming to be the best is easy, but proving it requires a strong resume. Parsian Atlas Crane Company, relying on years of experience and hundreds of successful projects across the country, has features that make it a reliable choice for crane construction:

1. Expert engineering team: Use of mechanical and electrical engineers with up-to-date knowledge of crane design.
2. Equipped manufacturing workshop: Use of advanced cutting and welding equipment for millimeter accuracy in the construction of the structure.
3. Guaranteed quality: Use of the best engine, gearbox and electrical parts brands in crane construction.
4. Competitive price: Elimination of intermediaries and direct supply. parts to reduce the customer's total cost.
5. Warranty and service: Provide valid written warranty and prompt support services.
6. Customization: Ability to design and manufacture special cranes for metal smelting, power plants, petrochemical, etc. industries.

Key points in buying and ordering crane construction

When making a contract for the construction of a crane, be sure to pay attention to the following:

• Receive technical calculations and executive drawings.
• Determining the exact brand of parts (electric motor, gearbox, switchboard) in the proforma invoice.
• Agreeing on welding and painting standards.
• Determining the exact schedule for delivery and installation.

Atlas Parsian Crane Company includes all these matters in its contracts in a transparent manner so that the employer can monitor the production process with ease. Transparency in performance is our basic principle in winning the trust of customers.

New technologies in the construction of cranes

Crane industry is progressing like other industries. Nowadays, intelligent condition monitoring systems are used in the construction of modern cranes. These systems are able to monitor the vibration, temperature and performance of the motors online and warn before the failure occurs. Also, anti-sway systems, which are implemented with the help of advanced drives, greatly increase the safety of handling. Atlas Parsian Crane Company is ready to implement these advanced options on its production cranes in line with the latest world technology.

conclusion

Manufacturing industrial and workshop cranes is a specialized process that requires experience, technical knowledge and appropriate equipment. A high-quality crane ensures the safety of your personnel and increases production efficiency. On the other hand, choosing the wrong contractor can lead to heavy repair costs and accidents.

Atlas Parsian Crane Company, with a deep understanding of the needs of the country's industries, is committed to providing you with a durable, safe and economical product. If you intend to order the construction of overhead, gantry or jib cranes, or if you need technical advice to equip your workshop, contact our experts today. We are by your side from the consulting stage to the final installation and commissioning, so that the wheel of your industry turns with strength and confidence. Remember that building a crane is not an expense, but an investment in the continuity and security of your business. Trusting the name of Parsian Atlas Crane Company is assurance of quality and commitment.
