vertical homogenizer mixer

A device with a horizontal axis that mixes different materials with a high speed so that the particles in the entire volume of the mixture are the same and the same size. Unlike the vertical models, in the horizontal type, heat transfer and the combination of heavier materials are done more easily.

main structure

1. Vertical tank (usually a cylinder of 304 or 316 steel)

2. Propeller or stator rotor (Rotor-Stator) - the main center of homogenization
3. Shaft and electric motor, sometimes with a gearbox to adjust the torque
4. Fluid or powder inlet/outlet
5. Thermal jacket (optional) for heating or cooling

Applications

| Industry | Common usage |

| Food Sauce, cream, paste, buttermilk, chocolate, extracts

| Cosmetic-sanitary | Cream, lotion, shampoo

| Medicinal Therapeutic suspensions and creams

| Chemical paint, glue, resin, industrial detergent |

Key Features

- The ability to create particles below 5 microns

- Uniform distribution of liquid and solid phase

- Ability to work continuously (Continuous) or periodically (Batch)

- Low contamination and easy washing (CIP/SIP)

- Lower energy consumption than the vertical model in large volumes

Common capacities and power

- Volume of mixture: from 100 to 5000 liters

- Engine power: from 3 to 45 kW

- Common material: 316L stainless steel for sensitive materials
