Name: 32 meter floor pump
Brand: other
Price: 70000000 IRR
Availability: InStock
Rating: 5 (1 reviews)

32 meter floor pump

General definition

The 32-meter skimmer pump is a type of submersible centrifugal pump whose impeller and motor are located in the middle part of the body (not on the bottom like a skimmer and not on top like a float).

That's why it's called a skimmer — that is, the motor is in the "waist" of the pump. This design provides balance, better cooling, and increased power in head and flow.

---

General technical specifications

| Feature | Usual value |

|--------|--------------|

| Pumping height (head) | 32 meters of water column |

| Dubai (watering) | About 20 to 30 cubic meters per hour |

| Outlet diameter (orifice) | Usually 2 to 3 inches

| Engine power 2 to 3 horsepower (1.5 to 2.2 kW) |

| Working voltage 220 V (single phase) or 380 V (three phase).

| Body material Stainless steel or 304 steel depending on the model

| Kind of butterfly Brass, noril fiber, or special cast iron

| Type of shaft (axis) | Stainless Steel 304 |

| Degree of motor protection (IP) | IP68 (fully waterproof) |

---

Functional features

- Ability to pump from medium depths (25 to 40 meters)

- Special design to increase efficiency in high head

- Uniform cooling by passing the water flow around the engine

- Lower energy consumption than screeds with higher efficiency

---

Applications

- Water pumping from semi-deep wells

- Irrigation of medium lands and greenhouses

- Water transfer in multi-story buildings and towers

- Water reservation systems and industrial tanks

---

Important points in selection and installation

1. The height is 32 meters, the maximum head of the pump; For continuous work, it is better to use it at a working height of about 25 to 28 meters.

2. The entry of solid particles or sand into the pump can damage the mechanical seal, so it is better to use a suction filter or a metal strainer.

3. The power cable of the pump must be according to the standard and have waterproof insulation H07RN-F.

4. Be sure to use the dry protection switchboard to prevent the engine from burning.

---

Common brands of 32 meter submersible pumps in Iran

- Pumpiran series models *290/3F or 290/4F*

- Electrogen model *E2-32*

- Leo (LEO) model *XQS32/2*

- Flora or Dab (DAB) — high quality but higher price

---

Difference with skimmer pump

| Feature | floor covering |

| Engine position Bottom of the body middle of the body |

| Water throw height Less (up to 28 meters) | more (up to 40 meters) |

| Energy efficiency Average | higher |

| Watering volume More | More balanced

| Application | Fast draining of water Continuous pumping from deeper wells and reservoirs
