   It has a vibrating system to prevent powder accumulation and maintain a uniform flow.

5. Powder transfer pump and hose:

The task of transferring the powder from the tank to the gun by air flow.

How the device works

The process includes four main steps:

1. Electric charge of powder through electrostatic field in gun.

2. Movement of powder particles towards the part (which usually has a ground connection).

3. Adhesion of powder particles to the metal surface due to electric potential difference.

4. Baking in a powder paint oven (180-220°C for 15-20 minutes) and forming a hard, shiny and resistant layer.

Types of powder paint machines

| Device type Application | Feature |

| manual | Small workshops and repairs Low price, easy transfer

| Linear automatic Large production units High speed, the ability to connect to the robot |

| simultaneous two-channel | Parts with two colors in one step Accurate control of color separation |

| Closed cycle recycling Large industrial lines Collecting unused powder and returning it |

---

## 🏗️ standards and safety

- EN 16985 (safety of powder paint application in spray room)

- ISIRI 8537 (Iranian national standard for epoxy-polyester powder paint)

- ASTM D3451 (Powder Coating Test Methods)

- CE Certification (for European equipment including unloading system and ozone control)

---

## 💠 Authentic brands and industrial samples

- GEMA (Switzerland) - the most famous automatic music in the world

- Wagner (Germany) – full robotic systems

- Nordson (USA) – with low consumption powder pumps

- Diamond Kaveh and Tehran Pashsh - authentic Iranian brands equipped with Kaveh Rang and Parsian Fam lines

---

## 💵 price determining factors

1. Gun type (manual or automatic)

2. Powder tank capacity (1 to 50 kg)

3. Number of voltage and current settings
4. Body material and heat resistance insulation
5. The existence of recycling system and cyclone filter

Average price in the second half of 1404:

- Simple manual device: 18 to 25 million Tomans

- Fully automatic device with HV and steel tank: 75 to 120 million Tomans.

*(based on the models of Kave Pashash and RangAfarin of Tehran)*

---

🌟 features of the resulting cover

- High resistance to corrosion and UV

- uniform coating with a thickness of 60-90 microns

- No streaks or brush marks

- Environmentally friendly and free of organic solvents
