Technical specifications

• Number of phases: three phases

• Output voltage: 680V line to line, star (Y) connection

• Frequency: 50 Hz

• Speed: 1500–1800 rpm

• Generator type: synchronous, brushless

• Installation type: horizontal stand (B3)

• Working environment temperature: up to 50°C

• Year of construction: 1995

⸻

Ability to convert voltage

This alternator has the ability to change from 680 V star connection to 440 V three-phase delta connection with the available terminals. This feature allows the device to be used for common industrial and factory systems and does not require an additional transformer.

⸻

Applications

• 1-2 MW diesel generators

• Oil, gas and petrochemical industries

• Large and industrial factories

• Small-scale power plants

• Vital centers and hospitals

⸻

Important maintenance tips

• Alternator is without a brush and does not need a brush service

• It is recommended to perform an insulation test and check the bearings before operation

• Set AVR and protections according to system requirements
