General specifications

Model

M350GB14

Dimensions

other

Technics M350GB14 control DC drive Made in England (Made in UK)

The M350GB14 drive from the reliable Control Techniques brand is a powerful industrial drive for controlling DC electric motors, which is designed and manufactured in England (UK) and is used for heavy and continuous industrial applications. With high power and the ability to withstand heavy currents, this drive is considered an ideal option for steel, cement, rolling industries, cranes, production lines and sensitive industrial machinery.

The M350GB14 drive is designed with a rated power of 125 kW and is capable of working with a three-phase 50/60 Hz network. The input voltage of this drive is in the range of 220 to 480 volts AC and in the output section, it provides a voltage equivalent to 250 to 530 volts DC to power the DC motor. This feature makes it possible to launch and accurately control high-power DC motors in different working conditions.

The rated output current of the drive is 350 amps and its input current is 292 amps. Also, this drive has the ability to overload 150% for 30 seconds, which ensures its reliable performance during start-up, sudden load changes and harsh industrial conditions. The software version installed on this drive is 05.01.00, which enables stable and precise control of the DC motor.

Control Techniques M350GB14 drive has international standards including CE and UL Listed (E58592) and is designed for industrial continuous duty. Compliance with safety requirements, including electric shock risk warning and the need to wait at least 5 minutes after a power cut, shows the professional and standard design of this product.

All in all, the M350GB14 is a British-made industrial DC drive with high build quality, long life and very stable performance, which is a reliable choice for sensitive and heavy-duty industrial projects.

Bahrani Industrial Group provides this drive to the country's industries by guaranteeing product authenticity and providing expert advice.
