"Rubber lifting bar"
It is used to transfer pistachios in pistachio processing lines and has two types of short steps and long steps.
Its short step type is used at the beginning of the line to transfer shelled pistachios with bunches to different pistachio peeler machines and feed the line, and its long step type is used to transfer peeled pistachios to other machines such as washing system, etc. .
The length and width of the elevator can be changed depending on the customer's needs and the position of the device in the pistachio processing lines.
This machine is placed before the tire wheel and the pistachio is guided into the machine by the top, and the machine separates the pistachio from the cluster and transfers the seeded pistachio into the tire wheel and the cluster and leaves out of the machine. This machine can be produced in different capacities of 3 tons and 6 tons.
This machine is placed at the beginning of the pistachio processing line and is responsible for peeling fresh pistachios, and this process is done by screws installed on a cylindrical hub. The device is designed in such a way that the act of replacing the screws is done easily and it also has the ability to design in different capacities.
"Pistachio peeling wheel (rubber model)"
This machine is used for peeling fresh pistachios. The peeling process in this machine is done by using several balls covered with rubber, after the pistachio passes through the rubber balls, the pistachio skin is separated due to friction and rubbing.
Peeled pistachios are entered into the dehulling part of the machine, and in this part, the pistachios that have not been peeled by the pistachio peeling wheel are peeled and the dulls are separated by a steel cylinder.
"conveyor belt"
This device is used to transfer materials from one device to another horizontally or with a gentle slope. This device is produced in different lengths and widths as a fixed and adjustable base.
1) Puck and dry pistachio garbage collector
2) Puck and pistachio litter picker
This machine is used in the pistachio processing line, and by air pressure, it separates the shelled pistachios, as well as garbage such as the skin and small pieces of pistachio clusters from the heavy pistachios and moves them out of the machine.
" Peel the fluff "
Whole pistachios, which have not been peeled by the pistachio peeler, are peeled by the fluff peeler using water and centrifugal force.
"Washing System"
After the pistachios are removed from the peeler and peeler, the pistachios enter the washing machine for washing. This device consists of a steel cylinder, the pistachios move forward by the spirals installed on the hub, and along the way, the pistachios are washed by the nozzles located on the top of the device. In addition to washing, the washing machine also performs the task of separating the small skins inside the pistachios. This device is produced and manufactured in two types, single and twin, for different capacities.
"Dehumidifier" After the pistachios pass through the washing machines and the water tank (in some processing lines), they enter this machine for moisture removal. The required hot air is provided by the corresponding heater and fan. While passing through this machine and being heated, the pistachios become slightly softer and as a result they have a better appearance. The movement system of the pistachios in this machine is such that the pistachios are completely upside down and the stirring causes the pistachios to dry evenly along the way. This device is designed and produced in two different capacities.
" Heater "
1) Gas heater
2) Gasoil heater
This device provides hot air for dehumidifiers, dryers and roasters to dehumidify, dry and roast pistachios.
Based on the type of fuel available and using gas and diesel burners, it is made in two types, gas and diesel. In the pistachio roaster, due to the need for hot air, the type of gas burner is used.
The basis of this heat transfer device is a furnace that is heated by a burner and by a fan, the air passes over the said furnace and produces hot air. The temperature of the outlet air can be adjusted by the thermostat that issues the command to turn the torch on and off.
1) End cap
2) twin gugir
This machine is used in the pistachio processing line to separate pistachios without skin from skinned and semi-skinned pistachios.
This device is designed and produced in 3 twin models with aluminum hub, dehumidifier head with steel hub and end cap with steel hub for different applications. The separation system of this device is based on friction.
"Dry Pond"
This machine can be used in the processing line of fresh and dry pistachios, and by air and vibration, shelled pistachios and half-shelled pistachios are separated from high-quality pistachios, and this machine can perform the following tasks.
1- Separation of dust and fine particles inside the pistachio
2- Separation of small and poor quality pistachios
3- Separation of shelled and half-shelled pistachios
4- Separation of stones and heavy objects in some models
" Blue Pond "
This device is placed before the dehumidifier and the process of separating the shell pistachio from the kernel is done by water. Poke pistachios, which are light, come to the surface and are collected by a spiral and are led out of the machine, and heavy pistachios settle on the bottom of the tank and are raised by a polyethylene chain lifter and transferred to the next machine. become
"Control Bar"
This device is used to transfer the product in dry processing lines. In the pistachio processing line, fresh pistachios are placed at the end of the line, and in the dry pistachio processing line, depending on the need, they are placed after the dry basin or sieve.
Bad quality pistachios are collected by people on both sides of the machine, and this machine is produced with a sanitary band in different lengths depending on the customer's order.
This machine is used to transfer pistachios and dry fruits. And due to the appearance of the device, it has the ability to transfer the product from a surface with a low height to a surface with a higher height, and it is produced in two models, one row and two rows.
Usually, it can be produced in the pistachio and other dry products processing lines from a height of 2 meters to a height of 9 meters.
"Full discharge dryer" This machine is used in the pistachio terminal and the pistachios are completely dried in this machine and ready to be sieved. The emptying system in this dryer is completely empty, and the contact surface of the pistachio with the shoulders and the body is completely steel, and the round of this machine can be adjusted, and the heating time of the pistachio can be changed by changing the round. The hot air of this dryer is supplied by a diesel heater.
"mechanical vibration" This machine is used to empty silos and hoppers and performs the emptying process uniformly and is used in different models for dry and wet pistachios, as well as in different sizes and places.
"sieve"
This device is used in dry pistachio terminals and separates pistachios linearly from fine to coarse and has 4 pistachio outlets and one soil outlet. The sheets on the sieve are equipped with a moving system and the sheet on the sieve can be replaced in about 2 minutes, and the machine is also equipped with a system to open the holes of the sheets and pistachios do not get stuck in the holes. This device can be produced with different capacities.
"Smile Separator"
This device is used to separate closed-mouthed pistachios from open-mouthed ones.
After passing through the funnel, the pistachios enter the rotating cylinder inside which special needles are installed, and while passing through the length of the cylinder, the open-mouthed pistachios are stuck to the wall of the cylinder by the needles and go to the top, where they enter the conveyor belt by special paddles. They are guided and exited from the machine, and the pistachios are guided out of the machine after passing through the length of the cylinder. These machines can be produced in different models and capacities.
