The design of low pressure electrical panel, which is one of the most used types of electrical panel, is important both for manufacturers and for those who intend to order and use this electrical panel. For design, it is necessary to know the important points related to it, to get familiar with the components and parts used, and also to know about the standards.
Familiar with low -pressure electrical panels
First, before getting acquainted with the design of the low pressure switchboard, it is better to get to know it more. In fact, the switchboard is a container whose internal components each perform a task to control or distribute the electric current. The voltage used in electrical panels is different based on their application. Therefore, 380 to 1000 volts are needed in the low voltage switchboard. Usually, these panels have high sales due to the use of low voltage and are considered more practical than other types. Also, these switchboards have different types, such as standing, wall, external or internal low pressure switchboards and rack switchboards.
What is the design of low -pressure power panels?
After getting to know the low voltage switchboard, it is time to design it. In order to do the correct design, we will explain this step by step.
Specify the type of board
The first step in designing a low pressure switchboard is to determine the type of switchboard based on the above. Of course, sometimes this type of order may be considered and designed according to the wishes of the customer. Drawing a map of the electrical panel After the type of low voltage switchboard is determined, a map is designed for it. In this map, the location of the components of the electrical panel will be determined along with the connections that are supposed to be made between the parts.
Select the components of low -voltage power panel
The next step after drawing the map is the preparation of the components of the high voltage switchboard or its parts. We name these components below: Box or box of electrical panel Miniature fuse with rail fuse Transformers, which include current and voltage transformers. Plastic channels Types of plastic and ceramic insulators Copper ingot or sheen Standard electrical wires Automatic type key that works as a key or fuse. Contactor Bimetal and photocells
Low -voltage power panel assembly
After the parts and components are determined, it is time to assemble the electrical panel, which is done based on the prepared plan.
