Principles of mechanical design of date juicing machine
General structure of the device
- Feeding section and date crusherIn this section, the dates enter the mechanical crusher after washing and separating the core. The design of the shredder blades is usually made of 304 or 316 stainless steel to have high resistance to the natural acid of the dates. Juice extraction section: In this step, the chopped dates release their juice with the help of an indirect heating system and mild mechanical pressure. The precise design of the mold and press angle is very important so that the extraction efficiency reaches more than 94%. Filtration and concentration section Filtration devices with fine steel mesh separate solid impurities and then in the vacuum concentration section, the juice reaches the desired concentration. The vacuum system preserves color and taste and reduces energy consumption.
Features of advanced mechanical design in Bandar Industrial Group devices
1. Durable and hygienic body design
2. Accurate and uniform heat transfer
3. Using an insulated thermal jacket
4. Designing powerful mechanical axes with industrial bearings
Optimizing energy consumption in date juicing machine
1. Use of indirect heating system
2. Vacuum tank design
3. Steam exhaust heat recovery
4. Insulation of the device structure
The main components of date juicing machine in Bandar models
1. The primary reservoir of dates
2. Crusher and compactor unit
3. Sap extraction system
4. Concentration and filtration unit
5. Control panel and safety system
Advantages of buying a device from Bandar Industrial Group
1. Dedicated design based on the required capacity
Bandar designs its machines in different capacities from 300 to 2000 kg/hour to cover the needs of small workshops and large factories.
2. Low fuel and electricity consumption
Thanks to the optimal design and closed heat transfer circuit, energy consumption per kilogram of production has been minimized.
3. Extensive after-sales service
Bandar Industrial Group provides full support with 12-month warranty and up to 10-year parts supply.
4. Use of standard parts
All parts are made from reputable national and foreign brands that increase the durability and efficiency of the device.
5. Complete production line design consultation
In addition to the date juicing machine, Bandar also designs and installs a complete washing line, grinding, concentrating, packing and final cooler.
Economic review and profitability of the device
An average workshop with a capacity of 500 kg of dates per hour is able to produce about 350 to 400 kg of high purity date juice daily. With the average selling price of each kilogram of date juice between 35 and 40 thousand tomans, the daily gross profit can be between 12 and 15 million tomans.
Optimization of energy consumption in port models has caused the cost of electricity and gas to be less than 10% of daily production income, which is considered premium.
Technical points in axle design, gearbox and power transmission system
In Bandar industrial models, the power transmission axis is directly coupled from the engine to the gearbox. This design reduces vibration and increases the life of the bearings. The body of the gearbox is made of high-pressure aluminum with passive cooling, which is resistant to heat.
The power transmission system to the press section is done through hydraulics with a double wall cylinder and gradual control valve. This structure causes the pressure to be applied in a soft and uniform way and the dates give juice without crushing too much.
Heat management and process temperature control
Health and safety tips in design
In the design of port devices, all the seams are sealed by tig welding method so that there is no point of contamination penetration. Also, the steam discharge system with an active carbon filter preserves the natural smell of dates and prevents environmental pollution.
conclusion
Mechanical design of date juicing machine requires high accuracy in material selection, heat flow design and compression system. The use of advanced technologies in optimizing energy consumption not only reduces production costs but also improves the quality of the final product to the export level.
Bandar Industrial Group has a lot of experience in manufacturing complete lines of date juice, and has been able to produce machines with high durability, low energy consumption and excellent efficiency. Choosing port equipment means choosing quality, economic efficiency and ensuring the future of investment in the date industry.
