What is a panel board?

General characteristics of panel board

• Made of fireproof PVC with high heat resistance
• There is a cover to cover and beautify the board
• Resistance to oil, dust and heat
• Common color: Grey, white, blue or industrial black
• Can be installed with screws or special glue on the metal surfaces of the board

Types of board ducts

1. Plain Duct

• Fast installation
• Suitable for large panels
• Has a tight cover to prevent cables from coming out

2. Slotted Duct

Features:

• Has vertical slits for convenient wire entry and exit
• Increases order and quick access during troubleshooting
• High resistance to bending
• Available in widths of 25, 40, 60 and 100 mm

3. Adhesive panel duct

The bottom of this duct has a special industrial adhesive and does not need screws or fasteners. It is mostly used for small panels and light control equipment.

Advantages:

• Easy and fast installation
• Suitable for environments without vibration
• Economical price

4. Network duct or bed floor duct

It is used for the passage of network and telephone cables in construction projects or control room floors.

Features:

• Special design to protect data wires
• Preventing severe bending of LAN cable

What is tracking?

Tracking Channel is actually a type of electrical channel or industrial duct that is used to pass cables in longer routes. Tracking is made of hard PVC or resistant ABS materials and is used as the main route for the distribution of cables in the factory or ceiling routes.

Tracking technical specifications

• Material: fire-resistant hard PVC
• Dimensions: from 20 to 100 mm wide
• Having a central or hinged cover
• Ability to install on the wall or device body

Application of tracking

• Guide the cables from the floor to the ceiling of the hall
• Use as the main way to connect the panels
• Prevent the cables from hanging or twisting

grooved channel

Slotted Wiring Duct is one of the most widely used wire paths in industrial switchboards. Its main difference with tracking in the internal design is that it has a groove and a regular distance for the cables.

Structural features of grooved channel

• Having grooved walls for exiting cables at different points
• Lockable cover for greater safety
• Standard design for the passage of command and signal wires
• Heat resistance between -15 and 85 degrees Celsius

benefits

1. Complete arrangement of wires
2. Ease of replacing or adding wires in the future
3. Preventing the cable from contacting live parts
4. Mechanical protection of wires against impact

Brands and quality

In the market of Yazd and Iran, the following brands are among the most popular options in the field of duct production and industrial tracking:

• Schneider Electric
• Legrand
• Den Masih
• Nusa and Alborz Electric

Pishro Sanat Yazd store, as industrial electrical equipment exchange in Yazd, supplies various models of panel duct and grooved channel of these brands, and by providing a guarantee of authenticity and competitive price, it is trusted by many electrical contractors and industrial panel designers.

Industrial duct and channel installation tips

1. Before installation, the surface of the board must be clean and dry.
2. Use a special saw for precise and clean cutting.
3. Ducts must be installed with a proper distance from power equipment so that heat does not damage the cables.
4. Always lock the covers completely to prevent cables from coming out.

The price of panel duct and grooved channel in Yazd

The price of each meter of duct or tracking varies according to width, depth, material and brand:

• Plain panel duct: from 25 to 50 thousand Tomans per meter
• Grooved channel: about 50 to 75 thousand Tomans per meter
• Industrial tracking surface: from 80 to 150 thousand Tomans per meter

In Pishro Sanat Yazd, all products are offered with authenticity guarantee and competitive price.

Summary

panel duct, tracking and grooved channel are vital requirements in the construction of electrical panel and industrial cable network. Choosing the correct type of duct according to the installation location, cable size and panel type will increase the safety, order and beauty of the electrical system.

If you are looking for a safe purchase and expert advice to choose the right type of duct and channel, Pishro Sanat Yazd is the best reference for you in Yazd; Sales representative of well-known brands and industrial electrical equipment exchange.
